高效率
內置過壓，過載，短路保護
浪涌保護2KV
符合BIS ROHS認證要求
high efficiency
Built in overvoltage, overload, and short circuit protection
Surge protection 2KV
Compliant with BIS ROHS certification requirements
| 功率 Power | 輸入電壓 Input Voltage | 輸出電壓 Output voltage | 輸出電流 Output Current | 效率 Efficiency | 外形尺寸 Overall Dimensions |
| 60W | 176-267V | 12V/24V | 6A/3A | 85% | L155*W50*H23 |
| 120W | 176-267V | 12V/24V | 10A/5A | 85% | L178*W50*H23 |
| 150W | 176-267V | 12V/24V | 12.5A/6.3A | 85% | L208*W50*H23 |
| 200W | 176-267V | 12V/24V | 16.6A/8.3A | 85% | L208*W50*H23 |
| 300W | 176-267V | 12V/24V | 25A/12.5A | 85% | L187*W60*H30 |
| 400W | 176-267V | 12V/24V | 33.3A/16.6A | 85% | L220*W60*H30 |
